Powerful Air Conditioner Radiator Copper and Aluminum Plate Shredder for Recycling
Product Details:
| Place of Origin: | China |
| Brand Name: | AITE |
| Certification: | CE ISO TUV |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | $8,990.00/sets 2-4 sets |
|
Detail Information |
|||
| Condition: | New | Plastic Type: | PVC, PET, PP/PE, PE, PP, PC, PMMA, PA, PS |
|---|---|---|---|
| Machine Type: | Plastic Shredder | Max.Production Capacity (kg/h): | 20000 |
| Production Capacity (kg/h): | 400 - 20000 Kg/h | Use: | Industrial Waste Shredder |
| Shaft Design: | Single | Voltage: | 380V/50HZ |
| Dimension(L*W*H): | 2800x1300x1850mm | Power (kW): | 30 |
| Weight (T): | 2.5 | Warranty: | 1 Year |
| Applicable Industries: | Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Home Use, Energy & Mining | Key Selling Points: | High Safety Level |
| Showroom Location: | Canada, Turkey, Viet Nam, Indonesia, India, Algeria, Ukraine | Machinery Test Report: | Provided |
| Video Outgoing-inspection: | Provided | Warranty Of Core Components: | 1 Year |
| Core Components: | Bearing, Motor, Pump, Gear, PLC, Pressure Vessel, Engine | Product Name: | Industrial Waste Radiator/medical Waste Shredder |
| Application: | Industrial Waste Disposal Industry | Input Size: | 200-2200mm |
| Function: | Waste Radiator Shredder | Advantage: | Easy Operation High Efficiency |
| Key Words: | Shredding Car Water Tank Radiator, Air Conditioner Radiator | Suitable Material: | Copper And Aluminum Plate, And Other Scrap Metal Materials |
| Final Product: | Standard-reaching Rate Is Higher Than 95%. | Usage: | Waste Raw Material Shredding |
Product Description
Product Overview
Industrial Waste Shredder/Waste Radiator Shredder
The radiator shredder is widely used in shredding car water tank radiator, air conditioner radiator, copper and aluminum plate, and other scrap metal materials. After the radiator is shredded, different kinds of metals can be sorted.
working principle
The blade of the metal shredder is made of high-strength alloy steel, which has the characteristics of strong wear resistance and high strength. The differential speed between the shafts has the functions of tearing, squeezing and biting. It is professionally designed for crushing metal. The design has the advantages of uniform discharge, large output and low noise. The electrical part adopts PLC control, with automatic detection of overload protection and other functions.
The metal shredder mainly relies on the principle of "shear and cut" to complete the process of crushing solid waste. The motor drives the reducer to transmit the torque to the movable knife of the crusher through the knife roller shaft, and the knife hook of the movable knife hooks the material down. Tear, the blade of the opposite roller cuts up solid waste like scissors, and the crushed materials and pre-screened materials are discharged from the bottom of the crusher.
The metal shredder mainly relies on the principle of "shear and cut" to complete the process of crushing solid waste. The motor drives the reducer to transmit the torque to the movable knife of the crusher through the knife roller shaft, and the knife hook of the movable knife hooks the material down. Tear, the blade of the opposite roller cuts up solid waste like scissors, and the crushed materials and pre-screened materials are discharged from the bottom of the crusher.
Knife Details Of The Metal Shredder
Everything can be shredded
Applicable industrial Waste Shredder Material:
What types of materials are processed?
It can be used to tear up solid materials such as plastic, rubber, fiber, paper, wood, electrical parts, cables, etc. which are hard to break, such as: nozzle material, rubber head, PET bottle, cardboard, circuit board, wood, plastic barrel, etc. You can select the corresponding model according to the material size and handling capacity. If users need to break especially hard
materials, such as nylon, ABS, PC and other high-strength engineering plastics, they need to explain the situation.
It can be used to tear up solid materials such as plastic, rubber, fiber, paper, wood, electrical parts, cables, etc. which are hard to break, such as: nozzle material, rubber head, PET bottle, cardboard, circuit board, wood, plastic barrel, etc. You can select the corresponding model according to the material size and handling capacity. If users need to break especially hard
materials, such as nylon, ABS, PC and other high-strength engineering plastics, they need to explain the situation.
PRODUCT SPECIFICATIONS
model | size(mm) | Shredder room(mm) | Blads(mm) | motor(k) | weight(k) | |||||
XD-600 | 2800×1300×1850 | 600×480 | 200 | 11×2 | 2200 | |||||
XD-800 | 3000×1300×1850 | 800×480 | 200 | 15×2 | 2500 | |||||
XD-1000 | 3300×1900×2200 | 1000×690 | 300 | 22×2 | 5200 | |||||
XD-1200 | 3600×2000×2200 | 1200×690 | 300 | 30×2 | 6400 | |||||
XD-1500 | 4180×2100×2400 | 1500×850 | 550 | 55×2 | 9000 | |||||
XD-1800 | 5800×2400×3300 | 1800×1206 | 550 | 75×2 | 13600 | |||||
XD-2000 | 6400×2700×3500 | 2000×1490 | 600 | 90×2 | 20100 | |||||
XD-2500 | 7500×3200×3800 | 2500×1800 | 600 | 110×2 | 25000 | |||||
more information please contact us, we can custom the product on your request | ||||||||||
Company Profile
Henan Xrido Environmental Protection TechnologyCo.Ltd.is a high-tech enterprise committed to the R &D, manufacturing and sales of mechanical equipment in the environmental protection and recycling industry.
we mainly focuses on design and manufacturing automatic waste segregation machine garbage sorter construction waste sorting equipment. include trommel screen machine, air separation machine, magnetic separators, garbage bag breaking machine, waste shredder machine, manual sorting tables, waste baling machine, chain plate feeder, belt conveyor.etc. Our machine has passed ISO9001:2000 CCC,CE certification.Our machines has already spread over the world.We can provide customers with one-stop service and solutions, complete equipment, on-site installation, and after-sales support.
SALES AND SERVICE NETWORK
FAQ
Q1: Are you a factory or a trading company?
A1: We are a professional manufacturer in China, passed Alibaba field certification.
Q2: How long is the warranty period?
A2: Normally 12 months. Except for wearing parts.
Q3: What’s your delivery time??
A3: We will arrange for shipping in factory within 15 working days after receiving the advance payment.
We provide the entire waste sorting line, including factory design, circuit routing, equipment placement, etc. Please feel free to contact us for details. Welcome to factory to discuss business cooperation.
A1: We are a professional manufacturer in China, passed Alibaba field certification.
Q2: How long is the warranty period?
A2: Normally 12 months. Except for wearing parts.
Q3: What’s your delivery time??
A3: We will arrange for shipping in factory within 15 working days after receiving the advance payment.
We provide the entire waste sorting line, including factory design, circuit routing, equipment placement, etc. Please feel free to contact us for details. Welcome to factory to discuss business cooperation.
