Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry

Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry

Product Details:

Place of Origin: China
Brand Name: AITE
Certification: CE ISO TUV

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: $6,500.00/sets 1-4 sets
Get Best Price Contact Now

Detail Information

Condition: New Video Outgoing-inspection: Provided
Machinery Test Report: Provided Marketing Type: Ordinary Product
Warranty Of Core Components: 1 Year Core Components: PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear
Warranty: 1 Year Material / Metal Processed: Stainless Steel, Brass / Copper, ALLOY, Carbon Steel, Aluminum
Power (kW): 30 Weight (KG): 2800
Key Selling Points: Multifunctional Applicable Industries: Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Construction Works , Other
Showroom Location: None Product Name: Two Shaft Waste Recycling Shredder Machine
Application: Recycling Industry Blade Material: Alloy Steel
Function: Waste Plastic Shredder Advantage: Easy Operation High Efficiency
Key Words: Two Shaft Shredder Suitable Material: Copper And Aluminum Plate, And Other Scrap Metal Materials
Final Product: Standard-reaching Rate Is Higher Than 95%. Usage: Electronic Waste, Plastic, Metal, Wood, Waste Rubber,

Product Description

Products Description

Double Shaft Shredder Machine

The Double Shaft Shredder can meet the waste recycling requirements of various industries, and is suitable for shredding thick and difficult materials, such as: electronic waste, plastic,tire, metal, wood, waste rubber, packaging barrels, pallets, etc.
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 0
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 1

Product Features

1、The double shaft shredder have been designed for a wide array of applications and industries, suitable for shredding solid material such as E-waste, metal, wood, plastic, scrap tires, packaging barrel, pallets, etc. 2、Depending on input material and the following process the shredded material can be used directly or go into the next step of size reduction. 3、It is widely used in industry waste recycling, medical recycling, electronic recycling, pallet recycling,municipal solid waste recycling, plastic recycling,tire recycling, paper making industry and etc.
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 2
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 3
Product Parameters
model
size(mm)
Shredder room(mm)
Blads(mm)
motor(k)
weight(kg)
XD-600
2800×1300×1850
600×480
200
11×2
2200
XD-800
3000×1300×1850
800×480
200
15×2
2500
XD-1000
3300×1900×2200
1000×690
300
22×2
5200
XD-1200
3600×2000×2200
1200×690
300
30×2
6400
XD-1500
4180×2100×2400
1500×850
550
55×2
9000
XD-1800
5800×2400×3300
1800×1206
550
75×2
13600
XD-2000
6400×2700×3500
2000×1490
600
90×2
20100
XD-2500
7500×3200×3800
2500×1800
600
110×2
25000
Notes:
1. The number of blade claws, diameter, and thickness can be customized according to the type of material and the size of the discharge.
2. The output of the equipment will be different depending on the type of material and the size of the discharge.
3. More information please contact us, we can custom the product on your request.
Product Application
Processable materials
1.Metal: aluminum can bundle, steel drum, car shell, color steel tile, bicycle, copper aluminum radiator, oil filter, scrap wires,cables, aluminum composite plastic panel, steel wire rope, gas tank, iron scrap, zip-top can, engine case, paint bucket, etc. 2.Plastic: plastic pallet, plastic drum, plastic bucket, plastic film, waste appliances shell, garbage plastic drum, IBC drum, IBC barrel,garbage bag, rubbish bag, plastic pipe, washing machine, forklift pallet, lead acid battery shell, etc. 3.Textile: scrap clothes, shoes, fishing net, woven bag, ton bag, jumbo bag, fishing net bundles, dust collector bag, industrial textile waste, etc. 4.Wood: wood mattress, wood furniture, wood pallet, scrap timber, sawdust chipboard, composite board, wooden door, forklift pallet, wood board, wood template, wooden case, wooden box, wood sofa, wood bed, etc. 5.Paper: scrap paper and cartons, including scrap books, carton board, carton box, packaging box, waste newspaper, office paper,printing paper, paperboard, etc. 6.Waste household appliances: TV, washing machine, refrigerator shell etc. 7. Pipes: large pipes, pipe fittings, PE pipes etc. 8.Scrap tires: car tires, truck tires etc. 9.All kinds of Kitchen waste, domestic waste, rdf derivatives, medical waste,garden waste etc.
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 4
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 5
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 6
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 7
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 8
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 9
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 10
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 11
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 12
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 13
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 14
Product Details

Working principle

Biaxial shredders use two-axis independent drive, so that the production of materials to produce the corresponding pressure, to achieve automatic feeding function, a unique knife shaft structure and four-corner rotary tool, low speed high torque in the production process.There will be no winding shaft, or stuck phenomenon of the device, thereby increasing the production efficiency, the device is suitable for all kinds of toughness, high viscosity material crushing.
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 15
Knife Details Of The Metal Shredder
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 16
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 17
Our Advantage
1. It has the characteristics of low speed, high torque and low noise. It is controlled by PLC. It has the functions of starting,stopping, reversing and overloading automatic reversing.
2. The motor + reducer drives the cutter shaft to achieve the shearing effect of low speed and high torque.
3. Bearing six-fold seal, effective waterproof and dust-proof, prolong the service life of bearings.
4. After tool wear, the repair technology of tool coating and welding is adopted to realize the repeated use of the tool, which greatly reduces the maintenance cost of the tool.
5. Separate box design, can easily and quickly remove the entire axle (axle, blade, bearing, sealing system).
6. Tools are arranged according to helix to achieve high efficiency cutting.
7. Both the inner hole and the spindle face of the cutter are designed in hexagonal form to realize the uniformity of the force exerted on the cutter.
8. According to different materials and product shapes to be torn up, different types of cutters can be selected
.
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 18
Successful Project
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 19
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 20
Company Profile
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 21
Henan Aite Environmental Protection Technology Co.Ltd.is a high-tech enterprise committed to the R &D, manufacturing and sales of mechanical equipment in the environmental protection and recycling industry.
We mainly focuses on design and manufacturing automatic waste segregation machine garbage sorter construction waste sorting equipment. include trammel screen machine, air separation machine, magnetic separators, garbage bag breaking machine, waste shredder machine, manual sorting tables, waste baling machine, chain plate feeder, belt conveyor.etc.
Our machine has passed ISO9001:2000, CCC,CE certification.Our machines has already spread over the world.We can provide customers with one-stop service and solutions, complete equipment, on-site installation, and after-sales support.
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 22
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 23
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 24
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 25
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 26
Function Multifunctional Double Shaft Tire Shredding Machines for Recycling Industry 27
FAQ
Q1: Are you a factory or a trading company?
A1: We are a professional manufacturer in China, passed Alibaba field certification.

Q2: How long is the warranty period?
A2: Normally 12 months. Except for wearing parts.

Q3: What’s your delivery time??
A3: We will arrange for shipping in factory within 15 working days after receiving the advance payment.

We provide the entire waste sorting line, including factory design, circuit routing, equipment placement, etc. Please feel free to contact us for details. Welcome to factory to discuss business cooperation.
